Product Description
The new E-Series non-faceted zero static tee maintains the essential functional characteristics of the original zero static valve design while improving the cost effectiveness of block body assemblies. The E-Series design features minimized exterior body machining, minimizing overall valve costs without affecting valve performance.
Types:
ZSBBT – Zerostatic Block Body T
ZSBBVV – Zerostatic Block Body Vertical Tube, Vertical Valve
ZSBBHV – Zerostatic Block Body Horizontal Tube, Vertical Valve
Download Literature
Standard Sizes:
- 0.25″ – 2″ (DN 8 – 50) Valve size
- 0.5″ – 4″ (DN 15 – 100) Run size
- *Other sizes available upon request
Materials:
- 316L ASTM – A479
- DN 177440, 1.4435
- AL6XN
- Hasteloy C-22 & C-276
- *Other materials available upon request
Standard End Connections:
- 14, 16, 18, 20 Gauge OD tubing
- DIN/ISO
- Tri-Clover Tri-Clamp®
- *Others available upon request
